SLK-R602 Series Industrial Cellular Router
Web：www.seriallink.nete‐Mail：info@seriallink.netMobilePhone：+86‐18682315199
2.3An t ennains tallation：
Connect one sm-head sucker antenna to the 3G/4G antenna interface and one WIFI connection to the
WIFI interface. Forcibly tighten, ensure the quality of reliable connection lest affect reception.
2.4UIM/SIM cardin stallation:
Insert the SIM card of the corresponding operator according to the router version purchased, and the
full-network version supports any operator SIM card. Installation method as shown:
HowtotakeouttheSIMcardsleeve?
When installing or removing the SIM card, press the yellow button on the left side of the SIM card holder
with a sharp object, and the SIM card sleeve will pop up. Note: if the machine has a SIM card from the
yellow button can a bit bigger, SIM card will pop up.
1. How to put the SIM card into the SIM card sleeve?
If it is Nano SIM card, please use the multi-in-one SIM card holder we give away. Installing a SIM
card, SIM card into the card sets first, SIM card sets missing Angle, and make sure that the SIM card
metal contact outwards.
2. How to insert SIM card correctly?
Core insert, the SIM card down and insert it into the finished card sets of will and the shell edge router
level.
Note: the card core must be pointed down at the SIM card jack when it is inserted. Release your hand
when you touch the SIM card slot to prevent the SIM card from falling into the machine.
SIM card installation diagram:
