10
To ensure that you have the most up to date parts
list you can download the latest version from the
internet by simply typing in the following URL and
selecting the file from the ‘downloads’ section.
www.myTSN.com/Serpent835
ART No. DESCRIPTION
808070 Serpent 835 2WD
808075 Serpent 835 4WD
Manuals & Decals
808185 Instructions-set up Serpent 835
808186 Reference guide Serpent 835
808187 Decal-sheet Serpent 835
Radio Installation
1634 Servo saver 1/10 universal
1636 Uni.throttle linkage
1637 Uni. Brake linkage
1619 Wire-guider nylon
1611 Servo lever 23T
1612 Servo lever 25T
1613 Servo lever 24T
8143 Track-rod set (2)
901161 Mounting bracket receiver
801171 Battery-case
801172 Battery-case connector
801170 Battery-set sealed-wired (4+1)
Fueltank
801155 Fueltank 75cc with filter and AFL-cap
1431 Fueltank foam seals /clip
1493 Pressure nipple (4)
1494 Silicone tubing 2x5x50 white
902115 Mounting-pin tank + rubber cap (2)
902116 Cap rubber for mounting pin tank (2)
1602 Tank-clips small (10)
801156 Tank-bracket rear
Ball Bearings
1312 Ballbearing 5X8X3 flanged
1342 Ball-bearing 6X13 HS Purple (2)
1343 Ball-bearing 10X19 HS Purple (2)
1344 Ball-bearing 12X18 HS Purple (2)
Shock Absorbers
909440 Shockabsorbers-set nylon key-4-step (2)
909441 Shock-parts nylon f+r key-type
909442 Pistons rod FR key hardened (2)
909444 Pistons rod RR key hardened (2)
909445 Shock-pistons fixed+adj (2)
909402 Pivot point upper (2)
909403 Ball-joint short 6mm ( 4)
909404 Spring support washer (4)
909405 Shock-adj nut alu + o-rings (4)
909406 Shock-cap-nut alu. (2)
909442 Pistons rod FR key hardened (2)
909444 Pistons rod RR key hardened (2)
6431 Membranes (4)
6442 O-ring for #909405 (10)
909407 O-ring set + washers
909414 Spring-set D=1.5 L=27-22.7 orange (4)
909415 Spring-set D=1.5 L=27-22.7 white (4)
909416 Spring-set D=1.6 L=27-22.7 yellow (4)
909417 Spring-set D=1.7 L=27-22.7 red (4)
909418 Spring-set D=1.8 L=27-22.7 blue (4)
Serpent H-Q Shockabsorber oil
1670 Silicone oil 20W
1674 Silicone oil 25W
1671 Silicone oil 30W
1675 Silicone oil 35W
1672 Silicone oil 40W
1676 Silicone oil 45W
1673 Silicone oil 50W
Chassis & Radio plate
808103 Chassisplate alu. 4mm T6
808110 Radioplate carbon 2mm
Bodymounts
808130 Bodyplate front
808138 Shocktower rear carbon + 6mm balls
808139 Shocktower rear carbon
808140 Bodymount-set rear TouringCar
808141 Body-support long front (2)
808142 Body-supports short front (2)
808143 Body-support set rear carbon + 808144
808144 Bodymounts universal
808150 Bodymount -set rear GTP EV2
808151 Pin lower bodymount EV2 (2)
808152 Bushing alu. threaded
808153 Bodymount rear GTP EV2
808154 Wishbone bodymount GTP EV2 (2)
808155 Centering unit nylon GTP EV2
909344 Pin upper bodymount (2)
Front Section
808120 Bumper
808201 Front bearing block left
808202 Front bearing block right
808203 Wishbone front upper left
808204 Wishbone front upper right
808205 Wishbone front lower left
808206 Wishbone front lower right
808207 Steeringblock left
808208 Steeringblock right
808210 Pivot pins front upper (2)
808212 Pivot pins front lower (2)
808215 Front wheelaxles 4wd (2)
808220 Front drive-shafts (2)
808221 Front axle alu with OW bearings
808229 Pulley / flange 24T frontshaft
1065 O-ring for alu front axle (10)
808222 Inner driveshaft adaptor (2)
808223 Q-C front levers aluminium (2)
808232 Spring quickchange system (4)
808245 Anti-roll bar set front adjustable
909215 Anti-roll bar levers + exc.
909216 Adj. Anti-roll bar male
909217 Adj. Anti-roll bar female
808125 Shocktower carbon front M2
Middle Section
801196 Radioplate bracket aluminum
801192 Chassis stiffener L carbon
801194 Chassis stiffener R carbon
808111 Spacer sideplate Left (3)
808250 Middle bracket 4wd
902252 Middle shaft
808265 Pully adaptor alu.
808225 Pulley/washer 16T middle shaft
808261 Pulley/washer 24T middle shaft
808360 Drive-belt front 4mm
808362 Drive belt side 4mm
8114 Roll-over bar
Rear Section
801331 Rear bearingblock left
801332 Rear bearingblock right
808355 Rear plate
801342 Diskbrake bracket
808356 Wishbone rear upper left
808357 Wishbone rear upper right
808358 Wishbone rear lower left
808359 Wishbone rear lower right
808311 Up-right low (1)
808312 Ball 9mm chromed (2)
808315 Pivot pins rear upper (2)
808317 Pivot pins rear lower (2)
808320 Rear wheelaxles set (2)
808323 Q-C levers rear alu (2)
808232 Springs quick-change system (4)
808325 Rear drive-shafts (2)
808337 Rear anti-roll bar 1.5mm
902138 Linkages rear anti-roll bar L+R (2)
1095 Shims nylon rear anti-roll bar (2)
808340 Nylon ball-cups set (12)
808342 Wheelaxle pin/shims set (4)
808344 Alu.adjusting nuts M10 (4)
808346 Pivot.balls 8.5mm (2)
Brake-System
901355 Brake pads black (4)
901356 Brake-plates steel (2)
9611 Brake –disk (2)
909356 Brake lever / spring
909248 Alu. brake/pully adaptor
909242 Pulley 22T 9mm
9618 Alu.collar brake-pulley
808349 Disk-brake cam hard anodised
Transmission
4WD
808370 Solid rear axle set
808373 Solid axle pully 47T
909242 Pully 22T
2WD
808390 Differential FPS
808391 Diff axle long FPS
808392 Diff axle short FPS
808393 Diff adj. Nut fps
808394 Diff friction steel plate set FPS
808395 Diff friction plate FPS (2)
808396 Diff pulley 47T + pins FPS + pro
808397 Diff FPS fastening material
808376 Diff pully 47T
6361 Rear belt kevlar 6mm
1326 Ballbearing 7x14
1330 Ballbearing 8x12x3.5 (2)
1373 Thrust bearing 6x14
1374 Thrust bearing 15x28x9 diff
2-Speed Gearbox
902410 2-speed gearbox LC (no shaft incl)
801415 2-speed axle 4WD 705-835
902415 2-speed clutch shoes set LC
902444 2-speed gear 44T (2ND) LC
902445 2-speed gear 45T (2ND) LC
902446 2-speed gear 46T (2ND) LC
902447 2-speed gear 47T (1ST) LC
902448 2-speed gear 48T (1ST) LC
902449 2-speed gear 49T (1ST) LC
902450 2-speed gear 50T (1ST) LC
6626 Springs / screws 2-speed
902411 Drive-flange alu with owb LC
902413 Clutch bell alu LC
902412 Adaptor 2-speed LC
902420 Needle steel 5X5 (2)
Clutch System
909510 Centax II clutch-set (excl. Flywheel)
909512 Centax II clutch-housing universal
909555 Centax gear-pinion alu. 15T
909556 Centax gear-pinion alu. 16T
909557 Centax gear-pinion alu. 17T
909558 Centax gear-pinion alu. 18T
909559 Centax gear-pinion alu. 19T
909560 Centax gear-pinion alu. 20T
6504 Conus flywheel (3)
6582 Centax clutch-nut
6585 Centax thrust washer
6584 Centax spring cup
6583 Centax pre-load adjusting nut
909514 Centax II bearing spacer 5x7
909516 Centax II spacer thrustbearing
6581 Centax flywheel 35mm
909518 Centax II coilspring 1.8
909515 Centax II centrifugal shoes (3)
6587XP Centax clutch shoe XP
6599 Centax shim-set 7x13 (10)
1093 Centax 5x6.8 shim-set 0.1 (2) 0.3 (1)
1377 Centax II thrust-bearing 5x10
Parts List - Serpent 835
