Introduction
PERFORMANCE THROUGH EVOLUTION
Parts list and Exploded views
The parts list and the exploded views for the
Serpent 835 are separate from the Instruction
manual. The exploded views show all the parts for
a particular assembly step, together with the
Serpent part number. In the parts list at the back
of this booklet you will find with the part number
the name of the part. Besides all the Serpent 835
parts as used in this car kit, you will also find in the
part list all the optional parts for the Serpent 835,
as well as a listing of general items like fasteners
and promotional items.
Serpent will regularly update the Serpent 835 parts
list and will make it available on the Serpent 835
product page on myTSN, check under ‘Downloads’.
This product page can be accessed directly at the
following address:
www.myTSN.com/Serpent835
Make sure to check out the Serpent 835 product
page on myTSN frequently. All information about
your car can be found here: publications, news
items, set-ups, FAQ’s, images, downloads, video’s
and interesting forums in several languages. MyTSN
provides you with an enormous amount of
interesting and often valuable information about
the Serpent 835, information provided by Serpent,
its factory and team drivers, and experienced users
from around the world. Often this information is
even available in several languages! If you’re not a
member of myTSN.com yet, sign up today and
experience why Serpent excels not only on the
track, but also on the Internet.
Contents
Description Page
1. Shock Assembly 3
2. Front Assembly 4
3. Rear Assembly / Differential Assembly 5
4. Radio Plate Assembly 6
5. Radio Plate Mounting 7
6. Gearbox Assembly 8
7. Centax Assembly 8
8. Final Assembly 9
9. Parts List 10
