REAR CAMBERLINK
DEFAULT POSITION
6.8 mm
REAR CAMBERLINK
LENGTH
21.1
M3x16
2mm
2mm
2
3
M3x6
M3x6
M3x8
21.2
M3x8 M3x6 M3x16
1
STEP 19
STEP 20
15
