Serpent Natrix 750-E - Page 31

45.3
45.1
45.2
SHOCKS LENGTH:
Measure the shock
length fully extended.
11.5
mm
Assemble the spring and spring-
cup (align correctly) to complete
the shock.
Push the shoch top and
the membrane into the
shock cap.
1- Fill up with sillicone oil
fully using the silicone
oil supplied in the kit.
For the correct cst value
please check the default
setupsheet.
2- Extend the shockrod fully
3- Move the shockrod
nwod dna pu ylwols
to let ALL air bubbles
escape.
4- Close top only 3/4.
1-Bleed: push the
shockrod all the way
in slowly, to allow
excessive oil to escape.
2- Close completely the
shock cap.
STEP 45
STEP 46
31
