Serpent VIPER 990e - Shock Length Adjustment

31
STEP 40
41.3
40.1
SHOCKSLENGTH:Measure the shock length
fully extended.
14
mm
15.5
mm
Assemble the spring and spring-
cup (align correctly) to complete
the shock.
Push the shock top and
the membrane into the
shock cap.
1- Fill up with sillicone oil
fully using the silicone
oil supplied in the kit.
For the correct cst value
please check the default
setupsheet.
2- Extend the shockrod fully
3- Move the shockrod
slowly up and down
to let ALL air bubbles
escape.
4- Close top only 3/4.
1-Bleed: push the
shockrod all the way
in slowly, to allow
excessive oil to escape.
2- Close the shock cap
completely.
FRONT
FRONT
REAR
REAR
40.2
STEP 41
