bag 14
35
FINAL ASSEMBLY
STEP 46 STEP 47
M3x10
M3x16
M3x10
5x8x2.5
3.2x7x0.5
3x6x8
5x8x2.5
Flanged
M3x10
Pinion is not included in the
kit. Assemble the proper
pinion for your set-up.
M3x16
M3x10
5x8x2.5 Flanged
5x8x2.5
3x6x8
3.2x7x0.5
