37
STEP 49
M3x6
M3x6
M3x14
M3x6
Nut M3
• Right and left batteries are not symmetrically placed.
• The default position of the battery brackets in order to have a proper weight
balance of the whole car is the showed by the red dots in the picture.
• It is possible to change the weight balance by moving the batteries
more forward (more understeer) or more rearward (less understeer).
The rearward position of the left side battery is not available with all pinion/
spur combination
