Servonaut M24 - Control Assignments for Robbe Lightset; Robbe Multi-Switch Assignments

35
Controls assignment for Robbe Multi-Switch Lightset 8413 or similar
Typ SM7 M24 MM4
a/1 3-Switch Starter/Horn
b/2 3-Switch Gearshifting
Servo output 1 only usable
without cruise control
c/3 3-Switch
L1 & S2, wiper Servo output
2
d/4
Pushb.-
Switch
Hazard lights
Output S3 not usable
Output L4 e.g. high beam
e/5 Poti Volume
f/6 3-Switch
Dumper/
Martin Horn
g/7 3-Switch
Parking/
driving
h/8 3-Switch Indicator L/R
M24
