WOOD BOILER INSTRUCTIONS Page 43 Copyright © 2011 Seton Wood Boilers all rights reserved
CLOSED BOILER AND RADIANT HEATING WITH DOMESTIC WATER HEATING
PLUMBING CLOSED RADIANT AND WATER HEATER
CIRCULATING PUMP
INSTALL ANTI-SCALD VALVE FOR DOMESTIC WATER
RADIANT SUPPLIES
RADIANT RETURNS
3/4” PEX
WATER
HEATER
SMALL
BRONZE
CIRCULATING PUMP
HOT OUT TO DOMESTIC
COLD IN DOMESTIC
BACKUP
BOILER
VALVE
DRAIN VALVE
EXPANSION
TANK
FILL VALVE
BALL VALVE
SETON
BOILER
