WOOD BOILER INSTRUCTIONS Page 52 Copyright © 2011 Seton Wood Boilers all rights reserved
1 INSTALL TAKAGI Page 52
RADIANT SUPPLIES
AND RETURNS
TO
WOOD
BOILER
CLOSED DOMESTIC WITH STORAGE TANK, WOOD BOILER AND BACKUP
INSTALL ANTI-SCALD VALVE FOR DOMESTIC WATER
TACO 008 or 0011
IRON PUMP
INSULATED
INDIRECT
WATER
HEATER
TAKAGI
INCOMING
COLD
ALL PLUMBING MUST BE PEX OR COPPER OR BRASS
NO CAST IRON OR GALVANIZED OR STEEL
1 INSTALL TAKAGI Page 52
INSULATED
STORAGE
TANK
