Specification
Tuner
Input Frequency Range: 950～2150MHz (C/Ku compatible )
Input Signal Level: －65～30dBm
RF Connector: F Type (input, output)
Input impedance: 75Ω
Demodulation Mode
Demodulation: QPSK, compatible with SCPC and MCPC
Symbol rate: 2～45 Mbit/s
Code rate: 1/2, 2/3, 3/4, 5/6, 7/8
Video decoding
Video decoding: ISO/IEC13818-2 MPEG2（MP@ML）Compatible
Video resolution: 720×576 (PAL), 720×480 (NTSC)
Video input code rate: 15Mbit/s Max.
Teletext: Support DVB-TXTETSI/EN300472
Audio decoding
Audio decoding : ISO/IEC13818－3
Audio Channel Mode: Stereo, Mixed two ch, Left ch, Right ch,
Audio Sample Frequency : 32，44.1, 48KHz
Power Specification
Power Input: AC 176~264V，50Hz
Power consumption: <5W
Power in Standby: <1W
Environment Requirement
Working Temperature Rang: 0-40
Working Humidity Range: <90%
Other:
Weight: < 1Kg
Packed measurements: 213×55×198 mm
Weight and dimensions are approximate
Specifications are subject to change without notice.
