Manual – MOVIDRIVE® MDX61B DRS11B Synchronous Operation Card

DRS1B synchronous operation card option

Fault Messages and List of Faults

8 Fault Messages and List of Faults

8.1 DRS1B synchronous operation card option

The following fault messages can occur specifically in synchronous operation. The fac-

tory set error response appears in the "Response (P)" column. (P) indicates that the

response is programmable (P83_ Fault response).

Fault

code

Designation

Response

(P)

Sub-

error

code

Designation Possible cause Measure

14 Encoder

Immediate

switch-off

0 Fault "Encoder".

Encoder not connected,

encoder is faulty

• Encoder cable or shield not

connected correctly

• Short circuit/encoder cable

has broken wire

• Encoder defective

Check encoder cable and

shield for correct connection,

short circuit and broken wire

25 Fault "Encoder"

Encoder fault X15 - Speed

range exceeded.

Encoder at X15 turns faster

than 6542 1/min.

26 Fault "Encoder".

Encoder fault X15 - Card is

faulty.

Error in the quadrant evalu-

ation.

27 Fault "Encoder"

Encoder connection or

encoder is faulty.

28 Fault "Encoder"

Encoder error X15 -

Communication error

RS485 channel.

29 Fault "Encoder"

Encoder error X14 -

Communication error

RS485 channel.

30 Fault "Encoder"

Unknown encoder type at

X14/X15.

31 Fault "Encoder"

Error plausibility check Hip-

erface X14/X15.

Increments were lost.

32 Fault "Encoder"

Encoder error X15 Hiper-

face.

Hiperface encoder at X15

reports error..

33 Fault "Encoder"

Encoder error X14 Hiper-

face.

Hiperface encoder at X14

reports error..

34 Fault "Encoder"

Encoder error X15

Resolver.

Encoder connection or

encoder is faulty..

Option

missing

Immediate

switch-off

0 Fault "Option missing"

Hardware is missing or not

permitted.

• Type of option card not

allowed

• Setpoint source, control sig-

nal source or operating

mode not permitted for this

option card

• Incorrect encoder type set

for DIP11B

• Use correct option card

• Set correct setpoint source

(P100)

• Set correct control signal

source (P101)

• Set correct operating

mode (P700 or P701)

• Set the correct encoder

type

2 Fault "Option missing"

Fault encoder slot.

3 Fault "Option missing"

Fault fieldbus slot.

4 Fault "Option missing"

Fault expansion slot.
