SI 300 Wall mounting / Desk type DIGITAL WEIGHT INDICATOR
Before starting the TEST mode, please remove operating devices.
5-5. Test Mode
5-5-1. Analog Check Mode
Under this mode, you can check analogue value to real digital value through Display. The last
digital value can be fluctuated
key 4 times  key  key
If there is no change although pressing keys or loading some
force on/in weighing part , it may something wrong with load
cell, cable, connector or A/D board. (-1048575~1048575)
5etUp
te5t
Press key 4 times then “SETUP”displays
input key to stard TEST mode.
TEST MODE 1
ESC / BACK
Analog value
Check Mode
Serial port test mode
Key/Digital Input
Check Mode
210375
121037
12103
: Displaying 1~100,000
: Displaying 10~1,000,000
: Displaying 100~10,000,000
210375
