DIGITAL WEIGHING INDICATOR
SI 4010
13
5. SET-UP
5-1. Calibration
Adjust weight balance between “Real weight” on the load cell(Weight Part) and “Displayed weight of
Indicator”. When you replace LOAD CELL or Indicator, you have to do Calibration process once again
5-2. Test Weight Calibration Mode (Using Test weight)
※remarks : In case that “P-W” is displayed, you have input the pass word to start
calibration mode.
Prepare At least 10% of Max. capacity of your weighing scale, and remove “CAL-BOLT” on the Front panel
and press “CAL - LOCK S/W” inside.
1. At normal mode, remove “CAL-BOLT” on the Front panel
123
2. And press “CAL - LOCK S/W” inside.
Check the “SET-CAL. Massage on display.
5et-Cal
※ For the save the each step, press key, for the cancel or move back, press key.
3. If you press key, Calibration Mode starts.
After displaying “CAPA”,
C999999
4. Please input Max capacity of your weighing scale,
And press key.
Ex) Load cell CAPA : 20kg, division : 0.001  Input 20000
C 20000
5. Define the optimal position or Decimal point
Whenever pressing key, Decimal point will be changed.
Ex) Load Cell CAPA : 20kg, division : 0.001kg  input 20.000
p 20.000
