SI 480E DIN SIZE WEIGHING CONTROLER
5-5-3. Key / Digital input Test Mode
Under this mode, you can test Key input and Digital
Key input test
Whenever pressing key pad or plus to digital input terminal, the matched No. will
be displayed on the each position.
4) Serial Interface Test Mode.
Connect with PC or other devices through serial interface
and check the transference and receipt.
At the normal operation, display will be blinked.
To test this mode, please use “TESTING Protocol”.
※ TESTING PROTOCOL.
※ If you send “Testing protocol” from PC to Indicator, at the normal operation Display
will blink.
First display position is for key pad input
Second display position is for digital input
↑↑↑↑
1234
1
11
11
C0rn1
