SI 550 WEIGHING INDICATOR
57
6-9-4. BIN OUT Card connection and Function
PIN No.
22
10
23
11
24
12
25
13
9
Function
Out1
Out2
Out3
Out4
Out5
Out6
Out7
Out8
Out COM
311-00
1
2
4
8
10
20
-
-
-
311-01
1
2
3
4
5
6
7
8-
-
6-10 BCD OUT Card (Weight data out)
6-10-1. Circuit composition 6-10-2. Card switch setting
Selectable Non-Invert or Invert by switch
on BCD OUT card PCB
6-10-3. BCD OUT card specification
MAX Input Voltage
30V 500mA
Remark: If BCD-OUT option is needed, F250 must set as 00
6-10-4. BCD OUT card connection
Switch
Standard
On operation
NON-INVERT
HIGH
LOW
INVERT
LOW
HIGH
Role
Pin No.
Role
Pin No.
1X1
19
4X10000
28
2X1
2
8X10000
11
4X1
20
1X100000
29
8X1
3
2X100000
12
1X10
21
4X100000
30
2X10
4
8X100000
13
4X10
22
COM
32
8X10
5
Net-weight
(HIGH)
31
1X100
23
Total weight
(LOW)
31
2X100
6
GND
1, 14
4X100
24
Disuse
15
8X100
7
Decimal point
0.000
33
1X1000
25
Decimal point
0.00
16
2X1000
8
Decimal point
0.0
34
4X1000
26
Mark
( Output : -)
17
8X1000
9
Disuse
35
1X10000
27
Disuse
18
2X10000
10
Overload
36
