SANITOP PAGE 5
20mm
100/110mm
Isolation valve
Vertical before
horizontal
Air Admittance Valve
Ø 20mm
max. 5m
3%
Ø 25mm
001 : 1
001 : 1
Isolation valve
Connections - Venting
• Where possible venting should always be made in a manner consistent with common plumbing practice venting requirements
referred to in Australian Standa
Sanitop
rds AS 3500 10:10 & 6:7:4.
• You can use suitable pvc pipe or plastic hose to run the vent, either to the open atmosphere or to an existing vent stack located nearby.
pod is recommended approximately every 12 months.
