SFE 95-STD1 - Page 89

SFE
87
ITEM NO. PART NO. DESCRIZIONE DESCRIPTION
95-STD1 Trasformatore 230/12 vac 230/12 ac power supply
1 95-ST1 Trasformatore 230/12/12 230/12/12 ac power supply for solenoid
95-STC1 Trasformatore 230/12/6 230/12/6 ac power supply for chlore
2 K-10020 Kit cavo cella cloro chloride cell cable kit
3 K-10019 Kit cavo elettrovalvola Electrovalve cable kit
4 K-10018 Kit cavo sensore volumetrico Meter cable kit
5 2221-*/05 Kit camma esterna External cam kit
6 K-10017 Kit accessori cablaggio Harnesses accessories kit
7 88-L2/05 Kit microswitch con supporto Microswitch and housing kit
8 40695 Kit cablaggio interno Internal harness kit
9 856-SFE-K1 Kit supporto controller e mascherina Controller plate and label kit
10
K-7930-03 Scheda elettronica sfe SFE electronic card
K-7930-02 Scheda elettronica sfe cloro SFE electronic card - chloride
11 94-R7K/05 Kit motore 12 vac, 1 rpm 12 vac motor, 1 rpm kit
12 81 Box standard Box standard
13 2253-BM/05 Kit pilota chiuso Blind driver kit
14, 15, 16 2253-AM/05 Kit pilota aperto Open driver kit
17 K-10029 Kit connettore esterno (controller /08, /09, c/07) External connector kit (/08, /09, c/07 controller)
18 468*-K1 Kit tiranti Connecting rod kit
19 433-KBM/05 Kit spalla sostegno piloti Drivers backplate kit
20 90 Blocca cavo Cord lock
Controller SFE piloti esterni / Timer SFE external pilots /
Controller SFE Piloten-Verteiler / Controlador SFE Pilotos externos /
Contrôleur SFE pilotes externes
910111213141516 171819 1
2
4
3
567
8
