Shark Cordless Detect Pro IW1600 Series User Manual

sharkclean.comsharkclean.com
AUTO-EMPTY ASSEMBLY (IW3600) NON-AUTO-EMPTY ASSEMBLY (IW1600)
1. Slide the Wand onto the neck of the Floor
Nozzle until it clicks into place.
2. Align the Hand Vacuum nozzle opening
with the top of the wand and slide it on
until it clicks into place.
3. Make sure the Dock is facing upright. Slide
the Charging Post into the slot on front of
dock until it clicks.
4. Place the dock on the floor near a wall
outlet. Plug the Power Cord into the outlet,
then connect the cord to the port on the
back of the charging post.
5. Store the crevice tool accessory on the
mount on the dock.
6. Refer to pages 5 and 6 for Odor
Installation and Replacement instructions.
For proper operation, ensure all components
are completely connected and clicked
into place.
1. Slide the Wand onto the neck of the Floor
Nozzle until it clicks into place.
2. Align the Hand Vacuum nozzle opening
with the top of the wand and slide it on
until it clicks into place.
For proper operation, ensure all components
are completely connected and clicked
into place.
Flex Wand
(on select
models)
Hand Vacuum
Storage Clip
Hand Vacuum
Storage Clip
Handheld
Vacuum
Handheld
Vacuum
Floor Nozzle Floor Nozzle
NOTE: Once the charging post is installed, it can’t be removed.
2.
(Click)
2.
(Click)
1.
(Click)
1.
(Click)
4. Power Cord
6.
Odor
Installation
3.
Assembled
Dock
5.
Accessory
Storage
