1 Using a coin, turn the 3 screws on the bottom of the floor
nozzle.
2 A portion of the base is hinged for better access to the
brushroll and exposure to the airway. Shine a flashlight from
the bottom of the base to check for blockages.
3 Remove any hair, fibers, or debris that may be wrapped
around the brushroll. There is a grove that allows a pair of
scissors to cut across to loosen the debris.
4 To reassemble, replace the base by lining it up along the
front of the nozzle. Rotate closed and lock the 3 screws.
CHECKING FOR BLOCKAGES
WARNING: To reduce
the risk of shock and
unintended operation,
turn power o and
unplug unit before
servicing.
TIP: You can also check
for blockages in the hose
and tubes. Just remove
floor nozzle, dust cup and
hose and shine a flashlight
in the openings.
BOTTOM OF FLOOR NOZZLE
STEP 1 STEP 2
STEP 3 STEP 4
