38
ADJUSTING THE FEED OVERLOAD
This machine is equipped with a safety overload which can be adjusted by the set
screw (Part # 73) located in the center of cover (Part # 75) which is located in the
center of the apron. (To increase tension turn clockwise, to reduce tension turn
counterclockwise). (Figure 13)
ADJUSTING HALFNUTS
1. Remove chasing dial assembly
2. Loosen 3 screws
3. Adjust half nuts and re-tighten the 3 screws
4. Test movement before reassembling.
(Figure 17)
