GEAR BOX ASSEMBLY
Item No.
Part Name
Amt. Used
Type: 16
Part No.
Type: 18
Part No.
1
Gear box
1
1210300307
1210300307
2
Cover-gear box
1
1210300101
1210300101
3
Gear-driven bevel
1
1210300405
1210300405
4
Pin-fixed
5
1210300503
1210300503
5
Pin-split
5
6
Claw-shifter
1
1210300601
1210300601
7
Claw-shifter
1
1210300709
1210300709
8
Claw-shifter
1
1210300807
1210300807
9
Claw-shifter
1
1210300905
1210300905
10
Claw-shifter
1
1210301000
1210301000
11
Set screw , M8xP1.25x8L
1
1210301108
1210301108
12
Cam-shifter
1
1210301206
1210301206
13
Collar
1
1210301304
1210301304
14
Set screw , M8x12
2
15
Ring-"O" , P18
2
16
Shaft-"A"
1
1210301402
1210301402
17
Pin-taper , 4x38
3
92010438
92010438
18
Pin-taper , 6x38
2
1210702301
1210702301
19
Collar-linkage
1
1210301500
1210301500
20
Hexagon socket head cap,
M6xP1.0x16L
6
21
Cap-right
1
1210301608
1210301608
22
Seal-oil
1
23
Bearing-ball , 6204
1
91301018
91301018
24
Gear-"B" shaft (36T)
1
1210301706
1210301706
25
Snap ring , S25
2
9171S025
9171S025
26
Gear-"B" shaft
1
1210301804
1210301804
27
Gear-"B" shaft
1
1210301902
1210301902
28
Gear-"B" shaft
1
1210302007
1210302007
29
Gear-"B" shaft
1
1210302105
1210302105
30
Gear-"B" shaft
1
1210302203
1210302203
31
Ball bearing
1
91301006
91301006
32
Snap ring , S20
2
33
Gear-"B" shaft
1
1210302301
1210302301
34
Key-square , 6x6x20L
2
35
Shaft-"B"
1
1210302409
1210302409
36
Bearing-ball , 6003
3
91301005
91301005
37
Cap-left
1
1210302507
1210302507
38
Hexagon socket screw ,
M6xP1.0x12L
6
39
Ring-"O" , P36
2
40
Shaft-"C"
1
1210302605
1210302605
41
Gear-"C" shaft
1
1210302703
1210302703
42
Bearing , 6203
2
91301016
91301016
43
Shaft-"D"
1
1210302801
1210302801
44
Key-square , 6x6x146L
1
45
Gear-"D" shaft
1
1210302909
1210302909
