Sharp 16 Series User Manual

42
APRON REMOVAL
1. Remove dowel pins from lead screw and feed shaft (Figure 4)
2. Remove chasing dial assembly (Figure 15)
3. Remove rotation lever assembly (Figure 15)
4. Remove lead screw bracket and slide lead screw & lead shafts out of apron
(Figure 16)
5. Removing 4 bolts will allow the apron to be removed. (Caution should be taken
when removing, due to its weight).
Notes:
