HEADSTOCK ASSMBLY (Spindle Bore80mm or 3")
Item No.
Part Name
Amt.
Used
Model: 17”(430)
Part No.
Model: 19”(480)
Part No.
Model: 21”(530)
Part No.
123
Shaft
1
3001123
3001123
3001123
124
Washer
5
3001124
3001124
3001124
125
Lever
2
3001125
3001125
3001125
126
Pin
2
3001126
3001126
3001126
127
Set screw,
M8xP1.25x10L
3
91120810
91120810
91120810
128
O-ring , P18xP1.0x14L
5
9151P018
9151P018
9151P018
129
Screw , M6xP1.0x14L
10
91160614
91160614
91160614
130
Lenz-oil , Ø 29
1
92552001
92552001
92552001
131
Spring pin , Ø 5x32L
9
92030532
92030532
92030532
Spring pin , Ø 5x26L
2
92030526
92030526
92030526
132
Snap ring , S12
3
9171S012
9171S012
9171S012
133
Snap ring , S10
2
9171S010
9171S010
9171S010
134
Set screw,
M8xP1.25x10L
2
91121020
91121020
91121020
135
Hexagon socket screw,
M10xP1.5x95L
2
91111095
91111095
91111095
136
Hexagon socket screw,
M6xP1.0x40L
4
91110640
91110640
91110640
137
Square key , 6x6x70L
1
91610608
91610608
91610608
138
Spring washer
1
