14
GEAR BOX ASSEMBLY
Item No.
Part Name
Amt. Used
Type: 16
Part No.
Type: 18
Part No.
90
Snap ring , S16
1
91
Hexagon socket screw ,
M6xP1.0x25L
2
91-1
Cover
1
1222100200
1222100200
92
Plug-oil inlet
1
1122101401
1122101401
93
Hexagon socket screw ,
M6xP1.0x65L
2
94
Seat-pilot light
1210701206
1210701206
95
Lead-screw (5 feet in)
1
1210700209
1210700209
(5 feet mm)
1
1210700101
1210700101
(6 feet in)
1
1220700202
1220700202
(6 feet mm)
1
1220700104
1220700104
(8 feet in)
1
1230700205
1230700205
(8 feet mm)
1
1230700107
1230700107
(10 feet in)
1
1240700208
1240700208
(10 feet mm)
1
1240700100
1240700100
96
Nut-lock
1
1210700709
1210700709
97
Bushing-leadscrew
1
98
Plug-leadscrew
1
1210700709
1210700709
99
Supporter-for leadscrew, feed rod
1
1210700807
1210700807
100
Plug-oil inlet
1
1122101509
1122101509
101
Hexagon socket screw ,
M8xP1.25x30L
1
102
Nut-lock
1
1210700709
1210700709
103
Plug-plastic
1
1122101607
1122101607
104
Rod-feed
1
1210700307
1210700307
105
Set screw , M6xP1.0x20L
2
106
Pin-taper , 6x100L
1
1210700601
1210700601
107
Hexagon socket screw ,
M8xP1.25x80L
1
108
Bushing-spindle starting rod
1
1210700905
1210700905
109
Rod-spindle starting switch
(5 feet)
1
1210700405
1210700405
(6 feet)
1
1220700408
1220700408
(8 feet)
1
1230700401
1230700401
(10 feet)
1
1240700404
1240700404
110
Seat-switch
1
1210701304
1210701304
111
Hexagon socket screw ,
M8xP1.25x25L
2
112
Snap ring , S30
1
113
Nut, M6xP1.0
1
114
Set screw , M6xP1.0x20L
1
1210305400
1210305400
115
Bracket
1
1210701402
1210701402
121
Pin , 5x25L
1
