190TW8 TV
Mechanical Instructions
Fig.10
10. Remove 3pcs screws from left side of bezel.
Fig. 11
11. Remove 3pcs screws from right side of bezel.
Fig.12
12. Separate bezel from panel.
Fig. 7
Fig. 8
8. Remove 8pcs screws from Speakers, and take off them.
Fig. 9
9.Disconnect the cable from Button/B.
7. Remove 2pcs screws from LED/B, and take off it.
14
