Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
32U-S600
32U-S710
47
PWB-A: DUNTKA526WED2(32U-S600)
PWB-A: DUNTKA526WED7(32U-S710)
MAIN UNIT(Continued)
SF201 RFiLC0405CEZZ J SAW Filter AH
L51 VP-CF270K0000 J Peaking 27µH AB
L201 VP-XF1R2K0000 J Peaking 1.2µH AB
L203 VP-DF100K0000 J Peaking 10µH AB
L401 VP-XF100K0000 J Peaking 10µH AB
L642 RCiLZ1027CEZZ X Coil AD
or
RCiLZ0798CEZZ
L671 RCiLZ1005CEZZ J Coil AH
å L701 RCiLFA010WJZZ X Coil AE
or
RCiLF0313CEZZ
or
RCiLF0273CEZZ
or
RCiLF0345CEZZ
å L702 RCiLF0313CEZZ J Coil AH
or
RCiLFA010WJZZ
or
RCiLF0273CEZZ
or
RCiLF0345CEZZ
L705 RCiLP0179CEZZ J Coil AD
L729 RCiLP0179CEZZ J Coil AD
L801 VP-DF100K0000 J Peaking 10µH AB
L802 VP-DF6R8K0000 J Peaking 6.8µH AB
L2040 RCiLB0159CEZZ J Oscillation Coil AE
or
RCiLB0131CEZZ
TRANSFORMERS
T201 RCiLi0636CEZZ X IF Coil AH
å T601 RTRNZ0057PEZZ R Transformer AK
'åT602 RTRNFA006WJZZ X H-Volt Transformer AY
å T702 RTRNW0005GJZZ X Transformer AP
or
RTRNW0005GJN1
CAPACITORS
[EL.··· Electrolytic, M-Poly.··· Metalized Polypro Film]
C53 VCEA0A1HW105M J 1 50V EL. AB
C54 VCEA0A1HW475M J 4.7 50V EL. AB
C55 VCEA0A0JW338M J 3300 6.3V EL. AD
C201 VCKYCY1HB102K J 1000p 50V Ceramic AA
C202 VCKYCY1HB103K J 0.01 50V Ceramic AA
C203 VCKYCY1HB102K J 1000p 50V Ceramic AA
C204 VCKYCY1HB103K J 0.01 50V Ceramic AA
C223 VCKYCY1CF104Z J 0.1 16V Ceramic AA
C224 VCEA0A1HW475M J 4.7 50V EL. AB
C225 VCKYCY1HB102K J 1000p 50V Ceramic AA
C226 VCEA0A1HW224M J 0.22 50V EL. AB
C227 VCEA0A1CW226M J 22 16V EL. AB
C228 VCKYCY1CF474Z J 0.47 16V Ceramic AB
C229 VCEA0A1AW228M J 2200 10V EL. AD
C230 VCEA0A1HW225M J 2.2 50V EL. AB
C231 VCKYCY1CF104Z J 0.1 16V Ceramic AA
C232 VCEA0A1HW474M J 0.47 50V EL. AB
C233 VCKYCY1CF104Z J 0.1 16V Ceramic AA
C361 VCEA0A1HW105M J 1 50V EL. AB
C362 VCQYTA1HM123J J 0.012 50V Mylar AA
C363 VCQYTA1HM123J J 0.012 50V Mylar AA
C364 VCEA0A1EW227M J 220 25V EL. AB
C365 VCEA0A1HW105M J 1 50V EL. AB
C366 VCEA0A1CW106M J 10 16V EL. AB
C367 VCEA0A1VW108M J 1000 35V EL. AD
C368 VCKYPA1HF103Z J 0.01 50V Ceramic AA
C369 VCEA0A1CW227M J 220 16V EL. AC
C370 VCEA0A1CW227M J 220 16V EL. AC
C371 VCEA0A1EW108M J 1000 25V EL. AD
C372 VCEA0A1EW108M J 1000 25V EL. AD
C373 VCKYCY1CF104Z J 0.1 16V Ceramic AA
C374 VCEA0A1HW225M J 2.2 50V EL. AB
C375 VCEA0A1HW225M J 2.2 50V EL. AB
C410 VCQYTA1HM104J J 0.1 50V Mylar AA
C419 VCKYCY1CF224Z J 0.22 16V Ceramic AA
C420 VCEA0A1CW476M J 47 16V EL. AB
C429 VCQYTA1HM103J J 0.01 50V Mylar AA
C433 VCKYCY1HB103K J 0.01 50V Ceramic AA
C434 VCEA0A1HW105M J 1 50V EL. AB
C435 VCQYTA1HM104J J 0.1 50V Mylar AA
C471 VCKYCY1HB822K J 8200p 50V Ceramic AB
(32U-S710)
C473 VCCCCY1HH561J J 560p 50V Ceramic AB
(32U-S710)
C475 VCKYCY1CF104Z J 0.1 16V Ceramic AA
(32U-S710)
C476 VCKYCY1HB103K J 0.01 50V Ceramic AA
(32U-S710)
C484 VCKYCY1HB103K J 0.01 50V Ceramic AA
(32U-S710)
C501 VCKYPA2HB102K J 1000p 500V Ceramic AA
C502 VCEA0A1VW108M J 1000 35V EL. AD
C510 VCFYSA1JB564J J 0.56 63V Mylar AE
C511 VCKYPA2HB391K J 390p 500V Ceramic AA
C512 VCQYTA1HM683J J 0.068 50V Mylar AB
C513 VCQYTA1HM103J J 0.01 50V Mylar AA
C514 VCEA0A1VW107M J 100 35V EL. AC
C515 VCEACA1HC225J J 2.2 50V EL. AC
C516 VCEACA1HC225J J 2.2 50V EL. AC
C517 VCEA0A1VW108M J 1000 35V EL. AD
C519 VCFYSA1JB473J J 0.047 63V Mylar AC
C551 VCEACA1HC474M J 0.47 50V EL. AB
C552 VCKYCY1HB392K J 3900p 50V Ceramic AA
C553 VCKYCY1HB392K J 3900p 50V Ceramic AA
C605 VCKYCY1HB102K J 1000p 50V Ceramic AA
C606 VCKYPA2HB561K J 560p 500V Ceramic AA
C607 VCKYPA1HB472K J 4700p 50V Ceramic AA
C608 RC-KZ0033CEZZ J 150p 2kV Ceamic AB
'åC609 VCFPFD3ZA912H J 9100p 1.8kV M-Poly. AD
'åC610 VCFPFD3ZA912H J 9100p 1.8kV M-Poly. AD
C614 VCKYPA2HB272K J 2700p 500V Ceramic AA
C615 VCKYCY1CF104Z J 0.1 16V Ceramic AA
C616 VCEA0A1HW224M J 0.22 50V EL. AB
C617 VCEA0A1HW474M J 0.47 50V EL. AB
C618 VCKYCY1HB822K J 8200p 50V Ceramic AB
C619 VCKYCY1HB103K J 0.01 50V Ceramic AA
C620 VCEA0A1CW477M J 470 16V EL. AC
C623 VCEA4A2EN106M J 10 250V EL. AD
C624 VCKYPA2HB102K J 1000p 500V Ceramic AA
C627 VCEA0A1HW106M J 10 50V EL. AB
C631 VCKYPA1HB331K J 330p 50V Ceramic AA
C632 VCEA0A1HW106M J 10 50V EL. AB
C633 VCKYPA1HB102K J 1000p 50V Ceramic AA
C644 VCFPVC2DB684J X 0.68 200V M-Poly. AG
C647 VCKYPA2HB102K J 1000p 500V Ceramic AA
C650 VCEA0A1HW105M J 1 50V EL. AB
C651 VCQYTA2AA104K J 0.1 100V Mylar AB
C652 VCEA0A1VW476M J 47 35V EL. AB
C653 VCEA0A1HW336M J 33 50V EL. AB
C654 VCFYFA1HA334J J 0.33 50V Mylar AB
C674 VCKYCY1CB104K J 0.1 16V Ceramic AB
C677 RC-FZ0377CEZZ J 4.7 50V Plastic AF
'åC678 VCQPPC2GB473J J 0.047 400V Plastic AB
C683 VRS-CY1JF000J J 0 1/16W M-Ox. AA
C684 VCEA0A1VW106M J 10 35V EL. AB
C685 VCQYTA1HM102J J 1000p 50V Mylar AA
C686 VCQYTA1HM104J J 0.1 50V Mylar AA
å C701 RC-FZ038SCEZZ J 0.047
AC125V
Plastic AE
or
RC-FZ030SCEZZ
or
RC-FZ022SCEZZ
C702 RC-KZ0029CEZZ J 0.01 500V Ceramic AC
To Next Page
