Sharp 32U-S600 - Main Unit

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
32U-S600
32U-S710
46
PWB-A: DUNTKA526WED2(32U-S600)
PWB-A: DUNTKA526WED7(32U-S710)
MAIN UNIT
TUNER
NOTE: THE PARTS HERES SHOWN ARE SUPPLIED AS AN
ASSEMBLY BUT NOT INDEPENDENTLY.
å TU51 VTUVTST5UF740 X Tuner AX
INTEGRATED CIRCUITS
å IC201 RH-iX3395CEN2 J TB1252CN AY
å IC361 VHiAN5276//-1 J AN5276 AR
å IC501 VHiTA8427K/-1 J TA8427K AL
IC680 VHiKiA358P+-1 R KIA358P AD
or
VHiiR9358//-1
or
VHiUPC358C/-1
å IC701 VHiTEA1507/-1 J TEA1507P/N1 AL
å IC702 RH-FX0008GEZZ J PC123FY8 AE
å IC703 VHiSE125N//-1 X SE125N AK
IC751 VHiSTV8164+-1 J I.C. AL
IC2001 RH-iXA192WJZZ X TMPA8700CSF AY
or
RH-iXA192WJN1
IC2040 VHiKiA7045A-1 J KIA7045AP AE
or
VHiKiA7045P-1
IC2101 VHiM24C16B/-1 J M24C16-BN6 AG
TRANSISTORS
Q201 VS2SC2735//1E J 2SC2735 AC
Q205 VS2PD601AR/-1 J 2PD601AR AB
Q206 VS2PD601AR/-1 J 2PD601AR AB
Q361 VS2PB709AR/-1 J 2PB709AR AB
Q402 VS2PB709AR/-1 J 2PB709AR AB
Q405 VS2PD601AR/-1 J 2PD601AR AB
Q410 VS2PD601AR/-1 J 2PD601AR (32U-S710) AB
Q471 VS2PD601AR/-1 J 2PD601AR (32U-S710) AB
Q472 VS2PD601AR/-1 J 2PD601AR (32U-S710) AB
Q473 VS2PD601AR/-1 J 2PD601AR (32U-S710) AB
Q474 VS2PD601AR/-1 J 2PD601AR (32U-S710) AB
Q601 VS2SC2482//-1 J 2SC2482 AD
å Q602 VS2SD2581++2E J 2SD2581++ AM
Q616 VS2PD601AR/-1 J 2PD601AR AB
Q634 VS2SC3198-G-1 J 2SC3198-G AA
Q650 VS2SA1266-Y-1 J 2SA1266-Y AA
Q672 VS2SA1266-Y-1 J 2SA1266-Y AA
Q673 VS2SD2045//-1 J 2SD2045 AL
å Q701 VSST9NC60FP1E X ST9NC60FP AP
Q727 VS2SC3333//-1 J 2SC3333 AG
Q728 VS2SA1091-O1A J 2SA1091-O1 AA
Q729 VS2SA1266-Y-1 J 2SA1266-Y AA
Q730 VS2SC3198-G-1 J 2SC3198-G AA
Q751 VS2SC3198-G-1 J 2SC3198-G AA
Q752 VS2PD601AR/-1 J 2PD601AR AB
or
VS2SC1623L61E
Q753 VS2SC3198-G-1 J 2SC3198-G AA
Q801 VS2PD601AR/-1 J 2PD601AR AB
or
VS2SC1623L61E
Q901 VSiMX1C/C//-1 J IMX1C/C// AB
Q902 VSiMX1C/C//-1 J IMX1C/C// AB
Q903 VSiMX1C/C//-1 J IMX1C/C// AB
Q908 VS2PD601AR/-1 J 2PD601AR AB
or
VS2SC1623L61E
Q2002 VS2SA1266-Y-1 J 2SA1266-Y AA
Q2059 VS2SC3198-G-1 J 2SC3198-G AA
Q2060 VS2PD601AR/-1 J 2PD601AR AB
or
VS2SC1623L61E
Q2201 VS2PD601AR/-1 J 2PD601AR AB
or
VS2SC1623L61E
Q2211 VS2PD601AR/-1 J 2PD601AR AB
or
VS2SC1623L61E
DIODES
D52 RH-EX0676GEZZ J Zener Diode, 32V AA
D53 RH-EX0619GEZZ J Zener Diode, 6.2V AA
D361 VHD1SS119//-1 J Diode AB
D362 VHD1SS119//-1 J Diode AB
å D501 RH-DX0302CEZZ J Diode AC
D510 RH-DX0441CEZZ J Diode AC
D511 RH-EX0654CEZZ J Zener Diode, 75V AD
D603 RH-EX0631GEZZ J Zener Diode, 9.1V AA
å D605 RH-DX0255CEZZ J Diode AC
D615 RH-EX0665GEZZ J Zener Diode, 25V AA
D621 RH-EX0631GEZZ J Zener Diode, 9.1V AA
å D622 RH-DX0131CEZZ J Diode AC
D650 RH-EX0628GEZZ J Zener Diode, 8.2V AC
'åD651 VHD1SS244//-1 J Diode AB
or
VHD1SS82///-1
'åD652 RH-EX0641GEZZ J Zener Diode, 8.2V AA
'åD653 VHD1SS119//-1 J Diode AB
D657 VHD1SS119//-1 J Diode AB
å D673 RH-DX0229CEZZ J Diode AF
D706 RH-EX0644GEZZ J Zener Diode, 13V AB
D707 VHD1SS119//-1 J Diode AB
or
VHD1SS244//-1
D708 VHD1SS119//-1 J Diode AB
or
VHD1SS244//-1
å D709 RH-DX0229CEZZ J Diode AF
å D712 RH-DX0468CEZZ J Diode AE
å D713 RH-DX0477CEZZ J Diode AF
D716 VHD1SS119//-1 J Diode AB
D717 RH-EX0650GEZZ J Zener Diode, 16V AB
D721 VHD1SS119//-1 J Diode AB
or
VHD1SS244//-1
å D725 RH-DX0407CEN1 X Diode AB
or
RH-DX0473CEZZ
D755 VHD1SS119//-1 J Diode AB
D801 RH-EX0631GEZZ J Zener Diode, 9.1V AA
D802 RH-EX0631GEZZ J Zener Diode, 9.1V AA
D2402 RH-EX0619GEZZ J Zener Diode, 6.2V AA
D2403 RH-EX0619GEZZ J Zener Diode, 6.2V AA
å VA701 RH-VX0019CEZZ J Varistor AC
or
RH-VX0048CEZZ
or
RH-VX0035CEZZ
PACKAGED CIRCUITS
å PR701 RMPTP0072CEZZ J Packaged Circuit AH
or
RMPTP0059CEZZ
X801 RCRSAA011WJZZ X Crystal AG
or
RCRSB0278CEZZ
FILTERS AND COILS
CF202 RFiLC0447CEZZ J Ceramic Filter AD
CF403 RFiLC0446CEZZ J Ceramic Filter AD
CF2040 RFiLA0099CEZZ J Ceramic Filter AE
