32U-S600
32U-S710
9
D07 EW PARABOLA 21 0-63(00h-3Fh) Must be set to "27"
D08 EW TRAPEZIUM 0E 0-31(00h-1Fh) Must be set to "0B"
D09 EW CORNER 0C 0-15(00h-0Fh) Must be set to "08"
D10 AFC GAIN 02 0-3(00h-03h) Must be set to "02"
D11 V EHT 07 0-7(00h-07h) Must be set to "04"
D12 H EHT 03 0-7(00h-07h) Must be set to "03"
EX1 FAO VOLUME 24 0-50(00h-32h) Must be set to "24"
EX2 CC-POSITION 21 0-127(00h-7Fh)
EX3 INT 7A 0-255(00h-FFh) Must be set to "7A"
EX4 A-ATT 5A 0-127
EX5 TUNER data 00 0-3(00h-03h) Must be to "00"
EX6 SYNC SLICE LEVEL 36 0-255(00h-FFh) Must be to "36"
OP1 OPTION1 F7 0-255(00h-FFh) Must be set to "F7"
OP2 OPTION2 F9 0-7(00h-07h) Must be set to "10" (32U-S600), "B9" (32U-S710)
OP3 OPTION3 0F 0-255(00h-FFh) Must be set to "0C" (32U-S600), "0E" (32U-S710)
M01 INPUT LEVEL 09 0-15(00h-0Fh) Must be set to "09"
M02 MTS VCO 24 0-63(00h-3Fh)
M03 FILTER 1F 0-63(00h-3Fh)
M04 WIDEBAND 18 0-63(00h-3Fh)
M05 SPECTRAL 10 0-63(00h-3Fh)
M06 ANT-B INPUT LEVEL 09 0-15(00h-0Fh)
M07 ANT-B WIDEBAND 18 0-63(00h-3Fh)
M08 ANT-B SPECTRAL 10 0-63(00h-3Fh)
M09 SRS LEVEL FF 0-255(00h-FFh) Must be set to "E0"
M10 BBE LEVEL FF 0-255(00h-FFh) Must be set to "D9"
M11 SRS & BBE LEVEL FF 0-255(00h-FFh) Must be set to "D0"
M12 SRS & BBE OFF LEVEL FF 0-255(00h-FFh) Must be set to "E5"
M13 SRS Effect 02 2-3(02h-03h) Must be set to "02"
Only for Model 32U-S710
M14 BBE-L Effect 08 0-15(00h-0Fh) Must be set to "0F"
M15 BBE-H Effect 08 0-15(00h-0Fh) Must be set to "0F"
M16 AGC level 07 0-7(00h-07h) Must be set to "01"
M17 BASS Offset 00 0-31(00h-1Fh) Must be set to "10"
M18 TREBLE Offset 00 0-31(00h-1Fh) Must be set to "10"
M19 BASS Offset-BBE 00 0-31(00h-1Fh) Must be set to "11"
M20 TREBLE Offset-BBE 00 0-31(00h-1Fh) Must be set to "10"
P01 CONTRAST-PIP 32 0-127(00h-7Fh)
P02 TINT-PIP 29 0-63(00h-3Fh) Must be set to "29"
P03 COLOR-SAT-PIP 32 0-127(00h-7Fh)
P04 Y-OFFSET-PIP 09 0-31(00h-1Fh) Must be set to "09"
P05 HXA-PIP 0A 0-255(00h-FFh) Must be set to "0A"
P06 HADJ-PIP 00 0-15(00h-0Fh) Must be set to "00"
P07 FREE RUN-PIP 0B 0-15(00h-0Fh) Must be set to "0B"
P08 TINT-PIP-INPUT 24 0-63(00h-3Fh) Must be set to "24"
SERVICE
NUMBER
DATA
ADJUSTMENT ITEM
INITIAL VALUE
RANGE
ADJUSTMENT CONTENTS
Table - A
NECESSARY UNNECESSARY
ADJUSTMENT
PART REPLACED
IC2001
IC201
X
Data is stored in IC2102.
The adjustment is needed to compensate for characteristics of parts
including IC201 and MTS level (M01).
Holding down both the VOL-up and CH-up buttons on the TV set at service mode for more than 2 seconds will
automatically write the above initial values into IC2102.
NOTES
X
IC2102 (or IC2101)
IC3001
CRT
IC1801
Holding down both the VOL-up and CH-up buttons on the TV set in
the service mode for more than 2 seconds will automatically write the
above initial values into IC2102 (or IC2101). Then perform a complete
adjustment.
Adjust items related to picture tube only.
Adjust items related to MTS only (M01~M20).
Adjust items related to P-IN-P only (P01~P08).
Table - B
X
X
X
X
