32U-S600
32U-S710
8
SERVICE
NUMBER
DATA
ADJUSTMENT ITEM
INITIAL VALUE
RANGE
V01 PICTURE 03 0-15(00h-0Fh)
V02 TINT 3E 0-127(00h-7Fh)
V03 COLOR 2D 0-127(00h-7Fh)
V04 SUB-COLOR 10 0-31(00h-1Fh) Must be set to "10"
V05 BRIGHT 4D 0-127(00h-7Fh)
V06 R CUT-OFF 40 64-255(40h-FFh)
V07 G CUT-OFF 40 64-255(40h-FFh)
V08 B CUT-OFF 40 64-255(40h-FFh)
V09 G DRIVE 40 0-127(00h-7Fh)
V10 B DRIVE 40 0-127(00h-7Fh)
V11 SHARP 14 0-63(00h-3Fh) Must be set to "1E"
V12 N PHASE 01 0-3(00h-03h) Must be set to "01"
V13 DC RESTORATION 00 0-3(00h-03h) Must be set to "03"
V14 BLACK STRETCH 03 0-3(00h-03h) Must be set to "03"
V15 ABL START POINT 03 0-3(00h-03h) Must be set to "03"
V16 ABL GAIN 02 0-3(00h-03h) Must be set to "02"
V17 γ POINT 00 0-3(00h-03h) Must be set to "02"
V18 Y-MUTE/V-STOP 00 0-2 "00"=Normal, "01"=No-Y, "02"=No-Y & No-Vertical
V19 ENERGY SAVE 28 0-63(00h-3Fh) Must be set to "28"
V24 LOW-G F7 0-255(00h-FFh) Must be set to "F7"
V25 LOW-B E8 0-255(00h-FFh) Must be set to "E8"
V26 ML-G 00 0-255(00h-FFh) Must be set to "00"
V27 ML-B F9 0-255(00h-FFh) Must be set to "F9"
V28 HIGH-G 03 0-255(00h-FFh) Must be set to "03"
V29 HIGH-B 06 0-255(00h-FFh) Must be set to "06"
V30 WPS 01 0-1 Must be set to "01"
V31 RGB CONTRAST 20 0-63(00h-3Fh) Must be set to "2A"
V32 Y-DL 02 0-7(00h-07h) Must be set to "02"
V33 Y-DL-INPUT 01 0-7(00h-07h) Must be set to "01"
V34 VSM GAIN 07 0-7(00h-07h) Must be set to "07"
V35 N COMB 01 0-1 Must be set to "01"
V36 BPF/TOF-INPUT 00 0-1 Must be set to "01"
V37 CORING 00 0-1 Must be set to "00"
V38 VSM PHASE 00 0-1 Must be set to "00"
V39 COLOR γ 00 0-1 Must be set to "01"
V40 SHARP-INPUT 14 0-63(00h-3Fh) Must be set to "1E"
V41 TINT-INPUT 3E 0-127(00h-7Fh)
V42 PICTURE-COMPONENT 03 0-15(00h-0Fh)
V43 TINT-COMPONENT 10 0-31(00h-1Fh) Must be set to "10"
V44 COLOR-COMPONENT 30 0-127(00h-7Fh) Must be set to "44"
V45 BRIGHT-COMPONENT 4A 0-127(00h-7Fh)
V46 R CUT OFF-COMPONENT 40 64-255(40h-FFh)
V47 G CUT OFF-COMPONENT 40 64-255(40h-FFh)
V48 B CUT OFF-COMPONENT 40 64-255(40h-FFh)
V49 G DRIVE-COMPONENT 40 0-127(00h-7Fh)
V50 B DRIVR-COMPONENT 40 0-127(00h-7Fh)
V51 SHARP COMPONENT 14 0-63(00h-3Fh) Must be set to "1E"
V52 N PHASE-COMPONENT 01 0-3(00h-03h) Must be set to "01"
V53 C-TRAP 00 0-1 Must be set to "00"
V54 ANT-B PICTURE 03 0-15(00h-0Fh)
V55 ANT-B TINT 3E 0-127(00h-7Fh)
Only for Model 32U-S710
V56 ANT-B COLOR 2D 0-127(00h-7Fh)
V57 ANT-B SHARP 14 0-63(00h-3Fh)
R01 RF-AGC 24 0-63(00h-3Fh)
R02 PIF VCO coil – —
R03 RF-AGC REF 5C 0-255(00h-FFh) Must be set to "5C"
D01 V POSITION 00 0-7(00h-07h)
D02 H POSITION 10 0-31(00h-1Fh)
D03 V SIZE 12 0-63(00h-3Fh)
D04 H SIZE 1F 0-63(00h-3Fh) Must be set to "1E"
D05 V-LINEARITY 07 0-15(00h-0Fh)
D06 V-S CORRECTION 08 0-15(00h-0Fh) Must be set to "09"
ADJUSTMENT CONTENTS
Table - A
To Next Page
