11
AF-06CSL
POWER
TEMP.
TEMP.
SELECTOR
SET TIMER/OFF
ON/OFF
• The time setting will change as you push the button. The display
will change as follows;
• The last OFF time setting is memorized by the unit and will
appear on the display when the button is pushed.
• The timer will be set, 5 seconds after the SET TIMER/OFF button
is pushed for the last time.
• If you wish to cancel the timer, push the SET TIMER/OFF button
again after the time is set or, push the SET TIMER/OFF button
until CL (cancel) appears on the display. A double beep will
sound when the timer is cancelled.
• The "ON" TIMER cannot be set with the remote control.
It can only be activated by the TIMER ON/OFF pad on the unit's
control panel ( See page 8).
TEMP.
TEMP.
---Raise temp. setting 1°F at a time.
---Lower temp. setting 1°F at a time.
OPERATING WITH THE REMOTE CONTROL
TRANSMITTER
TEMPERATURE setting button
POWER ON/OFF button
Push to start or stop the operation.
SELECTOR button
Push to change fan speed and operation
mode.
Fan speed and operation mode selec-
tions are shown to the right.
SET TIMER/OFF button
Push to set delay "OFF" timer during operation.
To change temperature setting when ON/OFF timer is in use
1. Push a TEMPERATURE setting button.
The current set temperature will be recalled on the unit's display.
2. Use the TEMPERATURE setting buttons to set the new temperature.
The new set temperature will show on the display for 5 seconds and return to
the time display.
HIGH COOL
MED COOL
LOW COOL
HIGH FAN
MED FAN
LOW FAN
0.5h
1.0h
1.5h 10h
Preset(0.5h)
Previous setting
11h12h
CL(cancel)
