36
AF-06CSL
REF. NO. PART NO. DESCRIPTION Q'TY CODE
HOW TO ORDER REPLACEMENT PARTS
To have your order filled prompty and correctly, please furnish the following information.
1. MODEL NUMBER 2. REF. NO. 3. PART NO. 4. DESCRIPTION
3-14 LHLD-A315JBF0 Thermistor holder 1 AE
3-15 PSEL-C289JBEZ Evaporator insulator 1 AC
3-16 LBND-A042JBE0 Wire fixing band 1 AC
ACCESSORY PARTS
4- 1 TINSEA300JBRZ Operation manual 1 AE
4- 2 LANGAA011JBFE Left closure frame 1 AH
4- 3 LANGAA012JBFE Right closure frame 1 AH
4- 4 PPLTPA016JBFB Closure 2 AK
4- 5 PSEL-A931JBE0 Window insulator 1 AH
4- 6 PSEL-A932JBE0 Window insulator 1 AE
4- 7 PSEL-C251JBEZ Window insulator 1 AC
4- 8 CFZK-B936JBKZ Closure ass’y 1 BA
4- 9 DX-BZA016JBK0 Screws kit 1 AW
4-10 SSAKAA018YDE0 Bag 1AB
4-11 XCTSD40P10000 Tapping screw 6 AA
4-12 XMPSD40P25000 Wood screw 7 AA
4-13 LANGAA030JBTA Base pan angle 2 AD
4-14 CRMC-A526JBEZ Remote control 1 AT
4-15 LHLD-A389JBFB Controller holder 1 AC
4-16 SPADBA163JBEZ Card board 1 AC
4-17 SSAKHA009JBEZ Bag 1AC
4-18 UBATUA027JBE0 Battery pack 1 AE
PACKING PARTS
5- 1 DPADBA004JBFZ Top pad ass’y 1 AH
5- 2 CPADBA046JBKZ Bottom pad ass’y 1 AN
5- 3 SPAKCB002JBEZ Packing case 1 AP
5- 4 SSAKHA245YDE0 Protect 1 AB
5- 5 SSAKAA053YDE0 Bag 1AB
SCREWS AND NUTS
6- 1 XTTSD40P20000 Tapping screw 4 AA
6- 2 XCTWJ40P16000 Tapping screw 2 AA
6- 3 XTTSD40P14000 Tapping screw 7 AA
6- 4 XTTSD40P12000 Tapping screw 14 AA
6- 5 XHTSD40P10000 Tap tight screw 6 AA
6- 6 XHTSD40P08000 Tap tight screw 4 AA
6- 7 XTPSD40P08000 Tapping screw 3 AA
6- 8 LX-BZA236JBE0 Special screw 1 AC
6- 9 LX-CZA038WRE0 Special screw 4 AA
6-10 LX-HZA001JBE0 Special screw 1 AB
6-11 LX-BZA140JBE0 Special screw 2 AB
6-12 XBPSD40P12J00 Machine screw 2 AB
6-13 LX-NZA074JBE0 Special nut 1 AB
6-14 LX-NZA148JBE0 Frange nut 1 AB
6-15 LX-NZA026JBE0 Special nut 3 AC
