AF-06CSL
REPLACEMENT PARTS LIST
REF. NO. PART NO. DESCRIPTION Q'TY CODE
CABINET AND UNIT PARTS
1- 1 DCHS-A441JBTA Base pan ass’y 1 BA
1- 2 CCAB-A316JBKZ Cabinet ass’y 1 BB
1- 3 LANG-A503JBTA Top inst. angle 1 BP
1- 4 PSEL-C357JBEZ Cabinet insulator 1 AC
1- 5 HPNLCA802JBFC Key sheet 1 AE
1- 6 HPNLCA815JBEA Control panel 1 AF
1- 7 PKESPA091JBFZ Condenser shroud 1 AS
1- 8 PSEL-C351JBEZ Condenser indulator 1 AC
1- 9 NFANPA106JBFZ Propeller fan 1 AR
1-10 CMOTLA998JBEZ Fan motor 1 BK
1-11 PSEL-A828JBE0 Motor insulator 1 AB
1-12 PSKR-A239JBFA Bulkhead 1 AX
1-13 PKESSA067JBFZ Caseing 1 AH
1-14 NFANSA027JBF0 Centrifugal fan 1 AU
1-15 PKESSA066JBFA Orifice 1 AH
1-16 MLOV-A321JBFA Vertical louver A 1 AC
1-17 MLOV-A322JBFA Vertical louver B 3 AC
1-18 MJNTPA089JBFA Louver joint 1 AC
1-19 MLOV-A323JBFA Horizontal louver 4 AC
1-20 MJNTPA090JBFA Louver link 1 AC
1-21 MSPR-A148JBEZ Louver spring 2 AF
1-22 GWAKPA150JBFA Front panel 1 AV
1-23 PFILMA162JBEA Air filter 1 AK
1-24 PSEL-C254JBEZ Tube insulator 1 AC
1-25 LHLDW0364JBE0 Wire holder 1 AA
1-26 LHLDW0366JBE0 Wire holder 2 AA
1-27 TSPC-E078JBRZ Name badge 1 AC
1-28 TLAB-C218JBEZ Energy card 1 AC
1-29 TLABBA110JBRA Sharp badge 1 AB
1-30 TLABKA564JBE0 Number card 1 AC
1-31 TLABMA326JBRZ Feature card 1 AE
1-32 TLAB-C277JBRZ Energy star label 1 AE
1-33 LBND-A042JBE0 Wire fixing band 2 AC
1-34 DSKR-A126JBKZ Bulkhead ass'y 1 AW
1-35 DKES-A029JBKZ Orifice ass'y 1 AW
CONTROL BOX PARTS
2- 1 DPLT-A057JBWZ Cont. box cover ass’y 1 AH
2- 2 DPLT-A058JBWZ Cont. box angle ass’y 1 AM
2- 3 LBNDKA104JBWZ Capacitor clamp 1 AG
2- 4 QACC-A260JBZZ Power supply cord 1 AS
2- 5 RH-HXA006JBZZ Thermistor 1 AK
2- 6 QW-VZC561JBE0 Lead wire 1 AD
2- 7 RC-HZA256JBE0 Fan motor capacitor 1 AM
2- 8 RC-HZA393JBE0 Running capacitor 1 AW
2- 9 TLABCB582JBRZ Wiring diagram 1 AA
2-10 DPWBFA244JBKZ Control board unit 1 BF
2-11 PSPA-A158JBZZ PWB Spacer 2 AD
2-12 PSPA-A159JBZZ PWB Spacer 1 AD
2-13 QFS-AA048JBE0 Fuse 1AB
2-14 LBND-A042JBE0 Wire fixing band 3 AC
2-15 QW-IZA038JBZZ Comp. Wiring 1 AS
2-16 PPLT-A299JBEZ Insulator sheet 1 AG
2-17 PPLT-A301JBEZ Insulator sheet 1 AA
CYCLE PARTS
3- 1 PCMPRA362JBEZ Compressor 1 BZ
3- 2 GLEG-A103JBE0 Compressor cushion 3 AG
3- 3 PPIPCF683JB1Z Discharge tube 1 AM
3- 4 PCON-A485JBEZ Condenser 1 BQ
3- 5 PPIPCF491JB1Z Lead tube 1 AF
3- 6 DCPY-A273JBKZ Capillary tube ass’y 1 AV
3- 7 PEVA-A461JBEZ Evaporator 1 BM
3- 8 CPIP-A029JBKZ Suction tube ass’y 1 AX
3- 9 PSEL-B160JBE0 Terminal gasket 1 AH
3-10 RHOG-A200JBZZ Overload relay 1 AU
3-11 MSPR-A114JBE0 Protector spring 1 AF
3-12 PCOV-A371JBE0 Terminal cover 1 AF
3-13 PSEL-B161JBE0 Gasket washer 1 AH
