2
AF-06CSL
SPECIFICATIONS
Models AF-06CSL
Cooling capacity BTU/h 6000
Moisture removal Pints/h 1.5
ELECTRICAL DATA
Phase Single
Rared frequency Hz 60
Rated voltage Volts 115
Rated current Amps 5.2
Rated input Watts 545
Power factor % 91
EER BTU/Wh 11.0
COMPRESSOR
Type (Hermetically sealed rotary type)
Model, Motor output 39R141AA-04P, 460W
REFRIGERANT SYSTEM
Evaporator Louver fin, Grooved tube, 7mm, Hair pin
Condenser Louver fin, Grooved tube, 7mm, Hair pin
Control O.D. x I.D. x Length x Q'ty(mm) 2.7 x 1.2 x 700 x 1
(Capillary tube)
Refrigerant volume R-22(OZ) 11.8
(Factory change)
NET DIMENSIONS
Width Height Depth inches(mm) 17-23/32(450) x 14-9/16(370) x 14-7/8(378)
Net Weight lbs 48
GROSS DIMENSIONS
Width Height Depth inches(mm) 20-7/8(530) x 18-1/8(460) x 18-3/8(467)
Gross Weight lbs 54
FAN SYSTEM
Indoor side(Evaporator) Centrifugal fan
Outdoor side(Condenser) Propeller fan
Air flow rate(indoor side) CFM High / Med / Low
195 / 175 / 150
OTHERS
Safety devices Compressor: Overload relay
Fan motor: Internal thermal protector
Air filter Polypropylene net
Power cord length ft 6.0
Power plug type 125V, 10A
ELECTRICAL PARTS
Running capacitor 250V-25µF
Fan capacitor 250V-6µF
Thermistor 15kΩ at 78˚C
Fan motor OBM-2016K1 (MLA998)
Overload relay B200-130-141E
