Sharp AH-S22DP2 - Electrical Parts

6
AH-S22DP2
AH-S25DP2
AH-S32DP2
For Model AH-S22DP2/S25DP2/S32DP2
DESCRIPTION MODEL REMARKS
Indoor fan motor ML-A901 220 - 240V, 50Hz 220 - 230V, 60Hz
Indoor fan motor capacitor – 430V or 450V, 2µF
Transformer – Primary; AC 220 - 240V, 50/60Hz
Secondary; AC19V
WPE1 – QFS-GA053JBZZ (2.5A, 250V)
For Model AU-S22DP2/S25DP2
DESCRIPTION MODEL REMARKS
Compressor 2RV110N5EA04 3-PHASE Induction motor
Outdoor fan motor ML-A902 220 - 240V, 50Hz 220 - 230V, 60Hz
Outdoor fan motor capacitor – 430V or 450V, 1.5µF
WPE1 – QFS-GA033JBZZ(15A, 250V)
WPE2 – QFS-GA015JBE0(10A, 250V)
WPE3 – QFS-GA054JBZZ (3.15A, 250V)
For Model AU-S32DP2
DESCRIPTION MODEL REMARKS
Compressor HV237A1-S15DK 3-PHASE Induction motor
Outdoor fan motor ML-A903 220 - 240V, 50Hz 220V, 60Hz
Outdoor fan motor capacitor – 430V or 450V, 2µF
WPE1 – QFS-GA014JBE0(20A, 250V)
WPE2 – QFS-GA019JBE0(20A, 250V)
WPE3 – QFS-GA054JBZZ (3.15A, 250V)
ELECTRICAL PARTS
