Sharp AL-1655CS - 10 Base plate unit 1

– 12 –
F
Base plate unit 1
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
1 CPWBF0147QSE7 AL E PPD1 sensor PWB
2 MLEVP0006QSZZ AD C PS front actuator
3 MSPRC0026QSZ1 AB C PS front actuator spring
4 XEBSE30P10000 AA C Screw(3×10)
5 PGIDM0010QSZ1 AG C TC front guide upper
6 XRESP50-06000 AA C E-ring
7 NROLR0013QSZZ AQ C PS lower roller
8 NBRGC0100FCZ1 AC C Bearing 6
9 NGERH0020QSZZ AG C Clutch gear(26T)
10 PPIPP0109FCZ1 AC C Pipe A
11 MSPRC1316FCZ1 AE C MF clutch spring B
12 XPSSJ20-07000 AA C Spring pin(φ2-7)
13 LBOSZ1851FCZZ AC C STK clutch boss
14 XRESP40-06000 AA C E-ring
15 LBOSZ1031FCZZ AC C Clutch boss
16 MSPRC0161QSZZ AF C Clutch spring
17 PPIPP0003QSZZ AD C Clutch sleeve
18 NGERH1132FCZZ AH C Clutch gear(29T)
19 NBRGP0562FCZZ AD C Bearing
21 NGERH0022QSZZ AC C Gear(33T)
22 NGERH0026QSZZ AD C Gear(21/29T)
23 NGERH0025QSZZ AD C W gear(30T)
24 CPLTM0024QS01 AG C PF plate 2
25 LPLTM0046QSZZ AE C PS earth plate
26 QSW-B0017QSZZ AF B Tray detect switch
27 DHAI-0269QSZZ AD C CED1 harness
28 GDAI-0001QSJ2 BE D Base plate
29 PSHEZ2026FCZ1 AB C Sheet M1 N
30 LHLDZ0017QSZZ AD C Plate holder
31 MSPRC0047QSZZ AA C Pressure plate spring
32 PCOVP0013QSZZ AD D Multi cover
34 LRALP0001QSJ2 AM C Base plate rail R
35 XEBSE40P12000 AA C Screw(4×12)
36 PSHEZ2174FCZZ AB C Paper feeding sheet
37 XBPSD30P08KS0 AA C Screw(3×8KS)
38 PCOVP0007QSJZ AE D Sensor cover
39 DHAI-0270QSZZ AD C D-RST harness
40 XEBSE30P12000 AA C Screw(3×12)
41 MSPRC0077QSZ1 AB C Front exterior lever spring
42 LPLTM0016QSZZ AE C Front exterior lever plate
43 LX-WZ0023FCZZ AA C Washer
44 XEBSE30P10000 AA C Screw(3×10)
46 NSFTZ0068QSZZ AR C Paper feed roller shaft
47 PCLR-0011QSZZ AC C Collar
48 LHLDR0095QSZZ AD C Paper feed roller holder
49 LBRCR0011QSZZ AD C Paper feed roller bracket
50 PGUMM0012QSZZ AG C Paper feed roller rubber
53 CPLTM0038QS02 AG C 2nd joint gear fixing plate
54 NGERH1169FCZZ AF C 2nd joint gear
55 XRESP70-08000 AA C E-ring
56 PSHEZ0470QSZZ AC C Rail R sheet F
57 PSHEZ0471QSZZ AC C Rail R sheet R
501 CSFTZ0068RS72 AX E Paper feeding shaft unit
