Sharp AL-2030

40
All About The Windows Event Manager and scanner events in
Windows 98, Windows Me, Windows 2000 and Windows XP.
Windows Platforms provide a mechanism for software to handle external events for
a scanner device like the SHARP AL-2040CS products. This mechanism is
controlled by the device manager on a device basis. Applications that can handle
events from a scanner/camera device register with the Windows Event Manager and
shown as available in the registered applications. The path an event takes to get to
the user's selected application depends upon the event settings for the device.
Scanner
AL-2040CS
SCAN key
pressed.
Event
Manager
Windows OS
Event
Manager
selection
dialog
Displayed on
screen
User selects
an
application.
The user
application
opens.
This is the Windows Event Manager
Selection Dialog.
Shown are two applications registered
to handle the scanner event from the
AL-2040CS device.
