Main
code
Sub
code
Content Remarks
Write in
memory
Adjustment
range
S-22 Displays counters.
S-22 01 Displays maintenance counter.
S-22 02 Displays maintenance counter preset.
S-22 04 Displays JAM counter.
S-22 05 Displays total counter.
S-22 06 Displays developer counter.
S-22 07 Displays developer preset counter.
S-22 08 Displays RADF counter.
S-22 09 Displays tray and ADU counter.
S-22 10 Displays staple counter.
S-22 12 Displays drum adjustment counter.
S-22 13 Displays key operator code.
S-22 14 Displays ROM version.
S-22 15 Displays trouble counter.
S-22 16 Displays copy counter.
S-22 17 Displays PDA/ZR print counter.
S-22 20 Displays printer counter.
S-23 Prints counter/adjustment values. “Printing is possible
after warming up (print
PWB is needed.)”
S-24 Clears special counters.
S-24 01 Clears JAM counter. PCU ---
S-24 02 Clears trouble counter. PCU ---
S-24 03 Clears tray and ADU counter. PCU ---
S-24 04 Clears RADF counter. PCU ---
S-24 05 Clears staple counter. PCU ---
S-24 07 Clears drum adjustment counter. PCU ---
S-24 08 Clears copy counter. PCU ---
S-24 09 Clears PDA/ZR printing counter. PCU ---
S-24 12 Clears printer counter.
S-25 Checks the activation of the main motor unit.
S-25 01 Checks activation of main motor drive unit.
S-25 02 Adjusts automatic developer. PCU 0-99
S-25 03 Sets toner control ignorance time during warm-up time. PCU 0-99
S-26 Setting.
S-26 01 Optional setting. PCU 0-15
S-26 02 Sets foolscap paper. PCU 1/2
S-26 03 Sets counter mode. PCU 0-3
S-26 06 Sets destination. PCU 1-9
S-26 15 Sets fusing curl correction mode. PCU 0/1
S-26 18 Sets toner save mode. PCU 1/2
S-26 26 Sets power save mode. PCU 0/1
S-26 27 Sets image density mode. PCU 1/2
S-27 Sets PPC communication parameters.
S-27 01 Sets PPC communication trouble. PCU 0/1
S-27 02 Sets PC/Modem telephone number. PC modem ---
S-27 03 Sets PC/Modem ID number. PC modem ---
S-27 04 Sets start/end of service. PC modem ---
S-27 05 Sets tag number. PCU ---
S-30 Displays the operating status of the paper/cassette sensors.
S-30 01 Displays the operating status of copier sensors.
S-30 02 Displays the operating status of paper size detection switch.
S-41 Checks document size detection sensor.
S-41 01 Checks document size detection sensor.
S-41 02 Adjusts document size detection sensor. PCU 0-255
S-41 03 Displays output value and setting of document size detection sensor.
9 – 4
