Main
code
Sub
code
Content Remarks
Write in
memory
Adjustment
range
S-42 Clears developer counter. PCU ---
S-43 Sets fusing temperature.
S-43 01 Sets fusing temperature (normal mode). PCU 160-205
S-43 02 Sets fusing temperature (economy mode). PCU 0-45
S-44 Sets process control mode.
S-44 01 Sets inhibit/enable of each mode of process control. PCU 0-3
S-44 02 Adjusts DM sensor.
S-44 03 Adjusts ID sensor.
S-44 04 Sets standard patch concentration. PCU 0-255
S-44 07 Checks gain selection between DM/ID sensors.
S-44 09 Displays process control data.
S-44 12 Displays DM/ID patch and drum base output.
S-46 Adjusts exposure level.
S-46 01 Adjusts exposure level (copy). Copy function available PCU AE: 30-170
ME: 30-170
PH: 30-170
SPH: 30-170
S-46 02 Inputs exposure level adjustment value (setting in each copy mode). PCU AE: 0-200
ME: 0-200
PH: 0-200
SPH: 0-200
S-46 03 Inputs exposure level adjustment value (copy). PCU See
Sim-46-01.
S-46 07 Inputs tone adjustment value (copy). PCU AE: 1-20
ME: 1-20
PH: 1-20
SPH: 1-20
S-48 Zoom adjustment.
S-48 02 Zoom adjustment (scanning direction). Copy function available PCU 0-20
SKN: 0-20
S-50 Adjusts the leading edge position of the copy.
S-50 01 Adjusts the leading edge of the copy (leading edge adjustment
value: RRC_A).
Copy function available PCU 0-99
Adjusts the leading edge of the copy (leading edge adjustment
value: RRC_B).
0-99
Adjusts the leading edge of the copy (trailing edge void: DEN_B). 0-99
S-50 02 Adjusts the leading edge of the copy (calculation formula). Copy function available. PCU 0-999
S-50 03 Inputs leading edge adjustment value, image loss. PCU 0-40
Inputs leading edge adjustment value,
leading edge adjustment value (copy). RRC_A
0-99
Inputs leading edge adjustment value, leading
edge adjustment value (copy/cassette). RRC_B
0-99
Inputs leading edge adjustment value, leading
edge adjustment value (copy/manual feed). RRC_B
0-99
Inputs leading edge adjustment value, leading
edge void (copy/cassette). DEN_A
0-99
Inputs leading edge adjustment value, leading
edge void (copy/manual feed). DEN_A
0-99
Inputs leading edge adjustment value,
trailing edge void (copy/cassette). DEN_B
0-99
Inputs leading edge adjustment value,
trailing edge void (copy/manual feed). DEN_B
0-99
Inputs leading edge adjustment value, leading
edge adjustment value (print/cassette). RRC_P
0-99
Inputs leading edge adjustment value, leading
edge adjustment value (print/manual feed). RRC_P
0-99
S-50 05 Adjusts the leading edge of image (print) printer. Copy function available PCU 0-99
S-50 10 Adjusts the print off-center (manual feed/cassette/ADU). Copy function available PCU 0-99
S-50 12 Adjusts document off-center (OC/RADF). Copy function available PCU 10-90
S-50 14 Inputs print off-center adjustment value. PCU
S-50 15 Inputs document off-center adjustment value. PCU
9 – 5
