Main
code
Sub
code
Content Remarks
Write in
memory
Adjustment
range
S-51 Timing adjustments.
S-51 01 Sets separation nail activation timing. PCU 20-90
S-51 02 Adjust resist amount, manual feed. Copy function available PCU 0-50
Adjusts resist amount, cassette. Copy function available PCU 0-50
Adjusts resist amount, ADU. Copy function available PCU 0-50
S-52 ADU adjustments.
S-52 01 Sets ADU alignment plate adjustment value. PCU 1-99
S-52 02 Sets ADU trailing edge adjustment value. PCU 0-99
S-52 03 Sets ADU drive clutch OFF time. PCU 0-10
S-53 RADF adjustment.
S-53 01 Adjusts RADF stopping position (normal paper, face side).
S-53 02 Adjusts RADF stopping position (normal paper, back side).
S-53 05 Adjusts RADF resist sensor. RADF ---
S-53 06 Adjusts RADF eject/inversion sensor. RADF ---
S-53 07 Adjusts RADF timing sensor. RADF ---
S-61 Laser output check.
S-61 01 Checks LSU activation.
S-61 02 Sets laser power. PCU 0-15
S-63 CCD activation checks.
S-63 01 Checks shading.
S-63 02 Sets shading white plate correction value. PCU ---
S-64 Self-printing.
S-64 01 Self-printing. “Printing is possible
after warming up”
S-67 Printer checks.
S-67 01 DRAM check. Printer PWB is needed.
S-67 02 Centronics port check. Printer PWB is needed.
S-67 03 Adjusts Centronics port timing. Printer PWB is needed
S-67 06 Writes flash font. Printer PWB is needed.
S-67 07 Compares and checks flash font. Printer PWB is needed.
S-67 08 Writes/compares and checks flash font. Printer PWB is needed.
S-67 09 Flash test. Printer PWB is needed.
S-67 10 Flash font sum check. Printer PWB is needed.
S-67 11 Sets select In signal. Printer PWB is needed. 0/1
S-67 12 Flash program writing Printer PWB is needed.
S-67 13 Flash program data comparison check Printer PWB is needed.
S-67 14 Flash program data write/comparison check Printer PWB is needed.
S-67 15 Flash program data sum check Printer PWB is needed.
