8. Detail of simulation
Main Sub
Item Content
Adjustment
code code range
01 Checks optical
system.
SIMULATION NO. 1- _
1.OPTICAL SYSTEM CHECK
2.OPTICAL SENSOR CHECK
INPUT SUB NO. AND PRESS PRINT SWITCH
01 Checks mirror
activation of
optical system.
• Execution wait mode
• Scanning in progress
[Content] When the [PRINT] key is pressed after entering a sub code, the copier enters the
execution wait mode, with the ready lamp coming on and the copy ratio indicating
100%. At this time, the copy ratio can be changed with the copy ratio key. After
that, if the [PRINT] key is pressed, the ready lamp goes out and the optical system
is initialized. The optical system is scanned once at the specified copy ratio. After
scanning, the copier returns to the execution wait mode.
(Ready lamp comes on and copy ratio remains unchanged.)
(a) Operation/display
[PRINT]: Starts scanning.
[PAUSE]: Stops execution and displays the sub code input screen.
[CA]: Stops execution and terminates the simulation.
[ZOOM UP]: Increases the copy ratio in steps of 1% up to 400%.
[NORMAL]: Returns copy ratio to 100%.
[ZOOM DOWN]: Decreases copy ratio in steps of 1% down to 50%.
[ENLARGEMENT]: 115 → 122 → 141 → 200 → 400 → 115
[REDUCTION]: 86 → 81 → 70 → 50 → 86
(The fixed copy ratio preset by a key operation is ignored.)
SIMULATION NO. 1- 1
OPTICAL SYSTEM CHECK
COPY RATIO
100%
PRINT SWITCH: EXECUTE SIMULATION
SIMULATION NO. 1- 1
OPTICAL SYSTEM CHECK
COPY RATIO
100%
[PAUSE]KEY: END ACTIVATION
