Main Sub
Item Content
Adjustment
code code range
01 02 Displays
operating status
of optical
system sensor.
SIMULATION NO. 1- 2
OPTICAL SENSOR CHECK
MHPS , RE , POWER
[PAUSE]KEY: END DISPLAY
[Content] Displays the operating status of the optical system and mirror motor.
MHPS: Mirror home position sensor
RE: Mirror rotary encoder pulse
POWER: Mirror motor drive power supply (+38 V)
(a) Operation/display
The display is in: Reverse video when sensor data is ON
Normal state when sensor data is OFF
[PAUSE]: The execution of the simulation is stopped and the screen returns to the
sub code input screen.
[CA]: The execution of the simulation is stopped and the simulation is terminated.
02 Checks RADF
aging.
SIMULATION NO. 2- _
1.RADF ACTION (AGING TEST)
2.RADF SENSOR CHECK
3.MOTOR A FORWARD ROTATION
4.MOTOR A REVERSE ROTATION
5.MOTOR B FORWARD ROTATION
6.MOTOR B REVERSE ROTATION
7.BELT CLUTCH ACTIVATION
8.PAPER FEED SOLENOID ACTIVATION
9.INVERSION SOLENOID ACTIVATION
INPUT SUB NO. AND PRESS PRINT SWITCH
01 RADF aging
test.
SIMULATION NO. 2- 1
RADF ACTION (AGING TEST)
[PAUSE]KEY: END ACTIVATION
[Content] RADF aging is started by manually turning ON the Document presence/absence
detection sensor.
(a) Operation/display
[PAUSE]: The execution of the simulation is stopped and the screen returns to the
sub code input screen.
[CA]: The execution of the simulation is stopped and the simulation is terminated.
9 – 8
