Main Sub
Item Content
Adjustment
code code range
02 02 Displays the
operating status
of the RADF
sensor.
SIMULATION NO. 2- 2
RADF SENSOR CHECK
DSD , DFD , DTD , RDD , AUOD
FGOD , TGOD , DED1 , DWS1 , DWS2
DWS3 , DWS4 , DLS1 , DLS2 , DWS
[PAUSE]KEY: END DISPLAY
[Content] The operating status of the RADF sensor is displayed.
Sensor Function Remark
DSD Document presence/absence
detection
DFD Document preliminary feed
detection
DTD Document resist sensor
RDD Document exit detection
AUOD DF section opening/closing
detection
FGOD Paper feed section opening/closing
detection
TGOD Inversion section opening/closing
detection
DED1 3rd document detection
DWS1 Document width detection 1
DWS2 Document width detection 2
DWS3 Document width detection 3
DWS4 Document width detection 4
DLS1 Document length detection
DLS2 Document length detection only for U.S. measure only
DWS Document pass width detection
(a) Operation/display
The display is in: Reverse video when sensor data is paper presence/door open
Normal state when sensor data is paper absence/door closed
[PAUSE]: The execution of the simulation is stopped and the screen returns to the
sub code input screen.
[CA]: The execution of the simulation is stopped and the simulation is terminated.
03 Checks forward
rotation of
paper feed
motor.
SIMULATION NO. 2- 3
MOTOR A FORWARD ROTATION
[PAUSE]KEY: END ACTIVATION
[Content] The paper feed motor of the RADF is rotated in forward.
(a) Operation/display
[PAUSE]: The execution of the simulation is stopped and the screen returns to the
sub code input screen.
[CA]: The execution of the simulation is stopped and the simulation is terminated.
9 – 9
