Main Sub
Item Content
Adjustment
code code range
02 04 Checks reverse
rotation of
paper feed
motor.
SIMULATION NO. 2- 4
MOTOR A REVERSE ROTATION
[PAUSE]KEY: END ACTIVATION
[Content] The rotation of the RADF paper feed motor is reversed.
(a) Operation/display
[PAUSE]: The execution of the simulation is stopped and the screen returns to the
sub code input screen.
[CA]: The execution of the simulation is stopped and the simulation is terminated.
05 Checks forward
rotation of
transport motor.
SIMULATION NO. 2- 5
MOTOR B FORWARD ROTATION
[PAUSE]KEY: END ACTIVATION
[Content] The rotation of the RADF transport motor is rotated in forward.
(a) Operation/display
[PAUSE]: The execution of the simulation is stopped and the screen returns to the
sub code input screen.
[CA]: The execution of the simulation is stopped and the simulation is terminated.
06 Checks reverse
rotation of
transport motor.
SIMULATION NO. 2- 6
MOTOR B REVERSE ROTATION
[PAUSE]KEY: END ACTIVATION
[Content] The rotation of the RADF transport motor is reversed.
(a) Operation/display
[PAUSE]: The execution of the simulation is stopped and the screen returns to the
sub code input screen.
[CA]: The execution of the simulation is stopped and the simulation is terminated.
07 Checks rotation
of paper eject
and inversion
motor.
SIMULATION NO. 2- 7
BELT CLUTCH ACTIVATION
[PAUSE]KEY: END ACTIVATION
[Content] The RADF belt clutch is turned ON.
(a) Operation/display
[PAUSE]: The execution of the simulation is stopped and the screen returns to the
sub code input screen.
[CA]: The execution of the simulation is stopped and the simulation is terminated.
9 – 10
