Main Sub
Item Content
Adjustment
code code range
02 08 Checks paper
feed solenoid
activation.
SIMULATION NO. 2- 8
PAPER FEED SOLENOID ACTIVATION
[PAUSE]KEY: END ACTIVATION
[Content] The RADF paper feed solenoid is turned ON.
(a) Operation/display
[PAUSE]: The execution of the simulation is stopped and the screen returns to the
sub code input screen.
[CA]: The execution of the simulation is stopped and the simulation is terminated.
09 Check inversion
solenoid
activation.
SIMULATION NO. 2- 9
INVERSION SOLENOID ACTIVATION
[PAUSE]KEY: END ACTIVATION
[Content] The RADF in version solenoid is turned ON.
(a) Operation/display
[PAUSE]: The execution of the simulation is stopped and the screen returns to the
sub code input screen.
[CA]: The execution of the simulation is stopped and the simulation is terminated.
03 Checks sorter
activation.
• SF-S15
SIMULATION NO. 3- _
2.SORTER SENSOR CHECK
3.TRANSPORT MOTOR ROTATION
4.SORTER BIN MOVING
5.FAN MOTOR ROTATION
6.GATE SOLENOID ACTIVATION
INPUT SUB NO. AND PRESS PRINT SWITCH
• SF-S53
SIMULATION NO. 3- _
2.SORTER SENSOR CHECK
3.TRANSPORT MOTOR ROTATION
4.SORTER BIN MOVING
6.GATE SOLENOID ACTIVATION
8.STAPLER MOTOR ROTATION
9.PAPER HOLD SOLENOID ACTIVATION
10.GUIDE BAR MOTOR ROTATION
INPUT SUB NO. AND PRESS PRINT SWITCH
9 – 11
