Main Sub
Item Content
Adjustment
code code range
03 02 Displays the
operating status
of sorter sensor.
• SF-S14
SIMULATION NO. 3- 2
SORTER SENSOR CHECK
PES , PWB-S , IULS , ILLS , IHS
IPS , SJS , UCSW , FCSW
[PAUSE]KEY: END DISPLAY
• SF-S53
SIMULATION NO. 3- 2
SORTER SENSOR CHECK
SPID , SPPD , BPED , SPED , SSD
BHPS , LCHPS , SGHPS , SHPS , JSW
SCSW , SCS , SED
[PAUSE]KEY: END DISPLAY
[Content] Displays the operating status of the sorter sensor.
• SF-S15
PES: Paper entry detection
PWB-S: Paper exit detection
IULS: Indexer upper limit detection
ILLS: Indexer lower limit detection
IHS: Indexer home position detection
IPS: Indexer fixed position detection
SJS: Sorter set detection
UCSW: Top cover opening/closing detection
FCSW: Floor cover opening/closing detection
• SF-S53
SPID: Paper entry detection (non sort)
SPPD: Paper entry detection (sort)
BPED: Bin paper detection
SPED: Staple position paper detection
SSD: Staple unit position detection
BHPS: Bin home position detection
LCHPS: Bin fixed-position detection
SGHPS: Guide bar home position detection
SHPS: Staple activation home position detection
JSW: Sorter set detection
SCSW: Staple cover opening/closing detection
SCS: Staple unit home position detection
SED: Staple needle detection
(a) Operation/display
The display is in: Reverse video when sensor data is paper presence/ door open/ON.
Normal state when sensor data is paper absence/door closed/OFF.
[PAUSE]: The execution of the simulation is stopped and the screen returns to the
sub code input screen.
[CA]: The execution of the simulation is stopped and the simulation is terminated.
9 – 12
