Main Sub
Item Content
Adjustment
code code range
03 03 Checks the
activation of the
transport motor.
SIMULATION NO. 3- 3
TRANSPORT MOTOR ROTATION
[PAUSE]KEY: END ACTIVATION
[Content] The transport motor of the sorter is turned ON.
(a) Operation/display
[PAUSE]: The execution of the simulation is stopped and the screen returns to the
sub code input screen.
[CA]: The execution of the simulation is stopped and the simulation is terminated.
04 Checks the
activation of the
bin shift motor.
<SF-S15 only>
SIMULATION NO. 3- 4
SORTER BIN MOVING
[PAUSE]KEY: END ACTIVATION
[Content] The activation of the sorter bin shift motor is checked.
The bin returns to the home position and stops at specified positions between 1st
and 20th (21st) bins, moving vertically.
(a) Operation/display
[PAUSE]: The execution of the simulation is stopped and the screen returns to the
sub code input screen.
[CA]: The execution of the simulation is stopped and the simulation is terminated.
05 Checks the
activation of the
fan motor.
SIMULATION NO. 3- 5
FAN MOTOR ROTATION
[PAUSE]KEY: END ACTIVATION
[Content] The fan motor of the fan is turned ON.
(a) Operation/display
[PAUSE]: The execution of the simulation is stopped and the screen returns to the
sub code input screen.
[CA]: The execution of the simulation is stopped and the simulation is terminated.
06 Checks the
activation of the
gate solenoid.
SIMULATION NO. 3- 6
GATE SOLENOID ACTIVATION
[PAUSE]KEY: END ACTIVATION
[Content] The sorter gate solenoid is turned ON.
(a) Operation/display
[PAUSE]: The execution of the simulation is stopped and the screen returns to the
sub code input screen.
[CA]: The execution of the simulation is stopped and the simulation is terminated.
