Main Sub
Item Content
Adjustment
code code range
03 08 Checks the
activation of the
staple motor.
<SF-S53N only>
SIMULATION NO. 3- 8
STAPLER MOTOR ROTATION
[PAUSE]KEY: END ACTIVATION
[Content] The activation of the sorter staple motor is checked.
When there is a paper at the staple section, stapling action is performed once.
(a) Operation/display
[PAUSE]: The execution of the simulation is stopped and the screen returns to the
sub code input screen.
[CA]: The execution of the simulation is stopped and the simulation is terminated.
09 Checks the
activation of the
paper holder
solenoid.
<SF-S53N only>
SIMULATION NO. 3- 9
PAPER HOLD SOLENOID ACTIVATION
[PAUSE]KEY: END ACTIVATION
[Content] The activation of the paper holder solenoid is checked.
(a) Operation/display
[PAUSE]: The execution of the simulation is stopped and the screen returns to the
sub code input screen.
[CA]: The execution of the simulation is stopped and the simulation is terminated.
10 Checks the
activation of the
guide bar motor.
<SF-S53N only>
SIMULATION NO. 3-10
GUIDE BAR MOTOR ROTATION
[PAUSE]KEY: END ACTIVATION
[Content] The activation of the guide bar motor is checked.
(a) Operation/display
[PAUSE]: The execution of the simulation is stopped and the screen returns to the
sub code input screen.
[CA]: The execution of the simulation is stopped and the simulation is terminated.
9 – 14
