Main Sub
Item Content
Adjustment
code code range
04 Checks the
activation of the
desk.
SIMULATION NO. 4- _
2.DESK SENSOR CHECK
3, 4.TRAY SIZE SWITCH CHECK
6.TRANSPORT MOTOR ROTATION
7, 8.LIFT UP MOTOR ROTATION
10.TRANSPORT CLUTCH ACTIVATION
11,13.PAPER FEED SOLENOID ACTIVATION
12,14.PAPER FEED CLUTCH ACTIVATION
INPUT SUB NO. AND PRESS PRINT SWITCH
02 Displays the
operating status
of the desk
sensor.
SIMULATION NO. 4- 2
DESK SENSOR CHECK
DPOD1 , DPOD2 , DDOP
DLUD1 , DLUD2
DPE1 , DPE2
[PAUSE]KEY: END DISPLAY
[Content] The operating status of the desk sensor is displayed.
DPOD1: Detection of paper exit of upper tray paper
DPOD2: Detection of paper exit of lower tray (LCC) paper
DDOP: Detection of side cover opening/closing
DLUD1: Detection of upper tray cassette lift up
DLUD2: Detection of lower tray (LCC) cassette lift up
DPE1: Detection of upper tray cassette paper
DPE2: Detection of lower tray (LCC) cassette paper
(a) Operation/display
The display is in: Reverse video when sensor data is paper presence/ door open/ON.
Normal state when sensor data is paper absence/door closed/OFF.
[PAUSE]: The execution of the simulation is stopped and the screen returns to the
sub code input screen.
[CA]: The execution of the simulation is stopped and the simulation is terminated.
